SKF 33018 -Tapered roller bearings, single row- Popular item SKF Bearing

    Buy cheap SKF 33018 -Tapered roller bearings, single row- Popular item SKF Bearing from wholesalers

    Buy cheap SKF 33018 -Tapered roller bearings, single row- Popular item SKF Bearing from wholesalers
    • Buy cheap SKF 33018 -Tapered roller bearings, single row- Popular item SKF Bearing from wholesalers
    • Buy cheap SKF 33018 -Tapered roller bearings, single row- Popular item SKF Bearing from wholesalers
    • Buy cheap SKF 33018 -Tapered roller bearings, single row- Popular item SKF Bearing from wholesalers
    • Buy cheap SKF 33018 -Tapered roller bearings, single row- Popular item SKF Bearing from wholesalers

    SKF 33018 -Tapered roller bearings, single row- Popular item SKF Bearing

    Ask Lasest Price
    Brand Name : SKF
    Model Number : 33018
    Price : Standard Precision
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000 PCS/MON
    Delivery Time : 3-15 DAYS
    • Product Details
    • Company Profile

    SKF 33018 -Tapered roller bearings, single row- Popular item SKF Bearing





    Bearing Type : Tapered roller bearings


    Brand :SKF


    Weigh : 2.2KG


    Material : Steel


    Flange Type : Non-Flanged Cup


    Scope application : Industria and Construction Machinery


    Inner Packing : Carton/wooden box, packaging with a woven belt


    Outer Packing : Carton/Wooden box


    Stock : Great Supplying Ability


    Supply a sample : Yes


    Bearing Specification


    d
    90 mm
    Bore diameter
    D
    140 mm
    Outside diameter
    T
    39 mm
    Total bearing width
    d1
    114 mm
    Inner ring shoulder diameter
    B
    39 mm
    Width inner ring
    C
    32.5 mm
    Width outer ring
    r1,2
    min. 2 mm
    Corner radius inner ring
    r3,4
    min. 1.5 mm
    Corner radius outer ring
    a
    27.389 mm
    Distance pressure point

    Abutment Dimensions

    da
    max. 101 mm
    Abutment diameter shaft
    db
    min. 101 mm
    Abutment diameter shaft
    Da
    min. 127 mm
    Abutment diameter housing
    Da
    max. 131 mm
    Abutment diameter housing
    Db
    min. 135 mm
    Abutment diameter housing
    Ca
    min. 7 mm
    Abutment housing - axial space at the large side face/ both sides of the outer ring
    Cb
    min. 6.5 mm
    Abutment housing - axial space at the small side face/ both sides of the outer ring
    ra
    max. 2 mm
    Fillet radius
    rb
    max. 1.5 mm
    Fillet radius

    Calculation Data


    C
    266 kN
    Basic dynamic load rating
    C0
    355 kN
    Basic static load rating
    Pu
    39 kN
    Fatigue load limit
    3 600 r/min
    Reference speed
    4 500 r/min
    Limiting speed
    e
    0.27
    Calculation factor
    Y
    2.2
    Calculation factor
    Y0
    1.3
    Calculation factor





    Product Picture


    Recommended Model



    GE40ES-2RS,GE45ES-2RS,GE50ES-2RS,GE60ES-2RS,GE70ES-2RS,GE80ES-2RS,GE90ES-2RS,GE100ES-2RS,GE110ES-2RS,GE120ES-2RS,GE140ES-2RS,GE160ES-2RS,XB-3,XB-4,XB-5



    Packing , Payment , Delievry and Stock


    Packaging
    1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet
    2)Industrial Bearings packaginga)plastic tube + carton + pallet
    b). plastic bag +kraft paper + carton + pallet
    3)According to the requirement of customers'
    Payment
    1) T/T:30% deposit, 70% should be paid before shipment.
    2) L/C at sight. (high bank charge, not suggest, but acceptable )
    3) 100% Western Union in advance. (especially for air shipment or small amount)
    Delivery
    1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient )
    2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive )
    3) More than 200 KGS, we will send by sea. ( Cheapest, but long time )
    Stock
    1)Availability and supply capacity on a certain basis
