LM29749/LM29711 bearing, TS series, single row tapered roller
bearing
Bearing Type : Tapered Roller Bearing |
Brand : NTN |
Cage material : Steel Cage |
Material : Case Carburized Steel |
Finish/Coating : Uncoated |
Scope application : Industria and Construction Machinery |
Inner Packing : Carton/wooden box, packaging with a woven belt |
Outer Packing : Carton/wooden box |
Stock : Great Supplying Ability |
Supply a sample : Yes |
Bearing Specification
TEMPERATURE RANGE [MIN] -40 °F
MATERIAL Case Carburized Steel
FILLET RADIUS 0.05 in
BEARING TYPE Cone & Cup
WIDTH ACROSS CUPS 0.71
FACTOR 1.80
BORE TYPE Round Bore
TEMPERATURE RANGE [MAX] 250 °F
INNER RING WIDTH 0.72 in
HOUSING SHOULDER DIAMETER - X (MAX) 2.44
NO. OF ROWS 1
INSIDE FILLET RADIUS 0.09 in
DYNAMIC LOAD RATING 9800 lbf
CUP NO. LM29710
LIMITING SPEED - GREASE 5500 rpm
O.D. 2.5625 in
LOAD CENTER -0.17 in
I.D. 1 1/2 in
INCH/METRIC Inch
OIL HOLE w/o Oil Hole
HOUSING SHOULDER DIAMETER - Z (MAX) 2.32
TOLERANCE Class 2
OUTER RING WIDTH 0.55 in
ENCLOSURE Open
STATIC LOAD RATING [MAX] 12800 lbf
CONE NO. LM29749
Bearing Size
Product Picture
Recommended Model
32005-X轴承 FAG S6200-2RSR FAG RTW617 FAG PCJT35-N-FA125 FAG
32232-A-N11CA FAG 22314-E1-K+H2314
FAG CSXF140 FAG 61815-2RSR-Y FAG CSXA045 FAG 3317-M FAG 23236-E1A-M
FAG 6010-2RSR
FAG 61820-2RSR-YFAG B71914-C-2RSD-T-P4SFAG B7230-E-T-P4SFAG
22217-E1-K+AHX317FAG GAKR14-PWFAG SL024960 and
other model
We also provide Brand Bearing
If you need, please contact us,Catalog and sample can be
offered,let me the model you need,i will quote to you For
reference.
TIMKEN,FAG,SKF,INA,NSK,NTN,KOYO,ASAHI,IKO Bearing
Packing , Payment , Delievry and Stock
| Packaging |
| 1)Commercial Bearings packaging: 1pc/plastic bag + color box +
carton + pallet |
| 2)Industrial Bearings packaging | a)plastic tube + carton + pallet |
| b). plastic bag +kraft paper + carton + pallet |
| 3)According to the requirement of customers' |
| Payment |
| 1) T/T:30% deposit, 70% should be paid before shipment. |
| 2) L/C at sight. (high bank charge, not suggest, but acceptable ) |
| 3) 100% Western Union in advance. (especially for air shipment or
small amount) |
| Delivery |
| 1) Less than 45 KGS, we will send by express. ( Door to Door,
Convenient ) |
| 2) Between 45 - 200 KGS, we will send by air transport. ( Fastest
and safest, but expensive ) |
| 3) More than 200 KGS, we will send by sea. ( Cheapest, but long
time ) |
| Stock |
| 1)Availability and supply capacity on a certain basis |
