628/8-2Z 628/8-2RS1 MINIATURE DEEP GROOVE BALL BEARING 8X16X5MM

Deep groove ball bearings 628/8-2Z

Bearing number : 628/8-2Z

Size (mm) : 8x16x5

Brand : SKF

Bore Diameter (mm) : 8

Outer Diameter (mm) : 16

Width (mm) : 5

Bearing dimensions and specification in SKF catalogue:

d - 8 mm

D - 16 mm

B - 5 mm

C - 5 mm

d1 - 10,1 mm

d2 - – mm

r1 min. - 9,4 mm

r2 min. - 9,4 mm

D1 - 14,2 mm

D2 - 0,2 mm

da min. - 10 mm

Da max. - 14,6 mm

ra max. - 0,2 mm

Weight - 0,0036 Kg

Basic dynamic load rating (C) - 1,33 kN

Basic static load rating (C0) - 0,57 kN

Fatigue load limit (Pu) - 0,024

Reference speed - 90000 r/min

Limiting speed - 45000 r/min

Calculation factor (f0) - 11

Calculation factor (kr) - 0,015
