Timken X32016X , Y32016X Tapered Roller Bearing Cone and Cup Set, Steel, Metric, 80mm ID, 125mm OD, 32016 Bearing

Product Categories
JFZ BEARING CO.,LTD
Contact Now
    Buy cheap Timken X32016X , Y32016X Tapered Roller Bearing Cone and Cup Set, Steel, Metric, 80mm ID, 125mm OD, 32016 Bearing from wholesalers

    Buy cheap Timken X32016X , Y32016X Tapered Roller Bearing Cone and Cup Set, Steel, Metric, 80mm ID, 125mm OD, 32016 Bearing from wholesalers
    • Buy cheap Timken X32016X , Y32016X Tapered Roller Bearing Cone and Cup Set, Steel, Metric, 80mm ID, 125mm OD, 32016 Bearing from wholesalers
    • Buy cheap Timken X32016X , Y32016X Tapered Roller Bearing Cone and Cup Set, Steel, Metric, 80mm ID, 125mm OD, 32016 Bearing from wholesalers
    • Buy cheap Timken X32016X , Y32016X Tapered Roller Bearing Cone and Cup Set, Steel, Metric, 80mm ID, 125mm OD, 32016 Bearing from wholesalers

    Timken X32016X , Y32016X Tapered Roller Bearing Cone and Cup Set, Steel, Metric, 80mm ID, 125mm OD, 32016 Bearing

    Ask Lasest Price
    Brand Name : TIMKEN
    Model Number : 32016
    Price : USD 0.5-10 PCS
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000 PCS/MON
    Delivery Time : 3-15 DAYS
    • Product Details
    • Company Profile

    Timken X32016X , Y32016X Tapered Roller Bearing Cone and Cup Set, Steel, Metric, 80mm ID, 125mm OD, 32016 Bearing



    Bearing Type : Tapered Roller Bearing


    Brand : TIMKEN


    Item Shape : Cup and Cone


    Material : Chrome Steel


    Closure Type : Open


    Scope application : Industria and Construction Machinery


    Inner Packing : Carton/wooden box, packaging with a woven belt


    Outer Packing : Carton/wooden box


    Stock : Great Supplying Ability


    Supply a sample : Yes


    Bearing Specification


    Specifications

    Series

    		32016X

    Cup Part Number

    		Y32016X

    Design Units

    		METRIC

    Full Timken Part Number

    		32016X

    Dimensions

    D - Cup Outer Diameter

    		125 mm4.9213 in

    C - Cup Width

    		22.000 mm0.8661 in

    Abutment and Fillet Dimensions

    r - Cup Backface "To Clear" Radius11.52 mm0.06 in

    Da - Cup Frontface Backing Diameter

    		119.90 mm4.75 in

    Db - Cup Backface Backing Diameter

    		114.05 mm4.49 in

    Specifications

    Series

    		32016X

    Cone Part Number

    		X32016X

    Design Units

    		METRIC

    Cage Type

    		Stamped Steel
    C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)1342000 N77000 lbf
    C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)288800 N20000 lbf

    Full Timken Part Number

    		32016X

    Dimensions

    d - Cone Bore

    		80 mm3.1496 in

    B - Cone Width

    		29.000 mm1.1417 in

    Abutment and Fillet Dimensions

    R - Cone Backface "To Clear" Radius31.520 mm0.06 in

    da - Cone Frontface Backing Diameter

    		87 mm3.43 in

    db - Cone Backface Backing Diameter

    		91 mm3.58 in

    Ab - Cage-Cone Frontface Clearance

    		3 mm0.12 in

    Aa - Cage-Cone Backface Clearance

    		2.3 mm0.09 in
    a - Effective Center Location4-1.8 mm-0.07 in

    Description

    This 32016X bearing is a metric taper roller bearing. The bearing's dimensions are 80x125x29mm

    32016X
    Tapered RollerVery Light Series, Wide80mm - Bore SizeISO bearing with same boundary dimensions as basic part number but with different internal geometry, yielding increased rating.



    Product Picture


    About this bearing

    • Cone (inner ring assembly) and cup (outer ring) combine to form a complete single tapered roller bearing
    • Supports both radial and axial loads between a rotating and non-rotating member
    • Operating temperatures range from -54 to 120 degrees C (-65 to 250 degrees F)
    • Stamped steel cage evenly spaces rollers for reduced friction, vibration, and noise
    • Open configuration for lubrication applied in place

    We also provide Brand Bearing


    If you need, please contact us,Catalog and sample can be offered,let me the model you need,i will quote to you For reference.


    TIMKEN,FAG,SKF,INA,NSK,NTN,KOYO,ASAHI,IKO Bearing


    Packing , Payment , Delievry and Stock


    Packaging
    1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet
    2)Industrial Bearings packaginga)plastic tube + carton + pallet
    b). plastic bag +kraft paper + carton + pallet
    3)According to the requirement of customers'
    Payment
    1) T/T:30% deposit, 70% should be paid before shipment.
    2) L/C at sight. (high bank charge, not suggest, but acceptable )
    3) 100% Western Union in advance. (especially for air shipment or small amount)
    Delivery
    1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient )
    2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive )
    3) More than 200 KGS, we will send by sea. ( Cheapest, but long time )
    Stock
    1)Availability and supply capacity on a certain basis
