SKF 628/8-2Z , 628/8-2RSRadial/Deep Groove Ball Bearing - Round Bore, 8 mm ID, 16 mm OD, 5 mm Width, Double Shielded

JFZ BEARING CO.,LTD
Contact Now
    Buy cheap SKF 628/8-2Z , 628/8-2RSRadial/Deep Groove Ball Bearing - Round Bore, 8 mm ID, 16 mm OD, 5 mm Width, Double Shielded from wholesalers

    Buy cheap SKF 628/8-2Z , 628/8-2RSRadial/Deep Groove Ball Bearing - Round Bore, 8 mm ID, 16 mm OD, 5 mm Width, Double Shielded from wholesalers
    • Buy cheap SKF 628/8-2Z , 628/8-2RSRadial/Deep Groove Ball Bearing - Round Bore, 8 mm ID, 16 mm OD, 5 mm Width, Double Shielded from wholesalers
    • Buy cheap SKF 628/8-2Z , 628/8-2RSRadial/Deep Groove Ball Bearing - Round Bore, 8 mm ID, 16 mm OD, 5 mm Width, Double Shielded from wholesalers
    • Buy cheap SKF 628/8-2Z , 628/8-2RSRadial/Deep Groove Ball Bearing - Round Bore, 8 mm ID, 16 mm OD, 5 mm Width, Double Shielded from wholesalers
    • Buy cheap SKF 628/8-2Z , 628/8-2RSRadial/Deep Groove Ball Bearing - Round Bore, 8 mm ID, 16 mm OD, 5 mm Width, Double Shielded from wholesalers

    SKF 628/8-2Z , 628/8-2RSRadial/Deep Groove Ball Bearing - Round Bore, 8 mm ID, 16 mm OD, 5 mm Width, Double Shielded

    Ask Lasest Price
    Brand Name : SKF
    Model Number : 628/8-2Z
    Price : USD 0.5-10 PCS
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000 PCS/MON
    Delivery Time : 3-15 DAYS
    • Product Details
    • Company Profile

    SKF 628/8-2Z , 628/8-2RSRadial/Deep Groove Ball Bearing - Round Bore, 8 mm ID, 16 mm OD, 5 mm Width, Double Shielded



    Bearing Type : Deep Groove Ball Bearing


    Brand : SKF


    Bore Type : Cylindrical

    Material : Steel


    Seal Type : Non-contacting seal


    Scope application : Industria and Construction Machinery


    Inner Packing : Carton/wooden box, packaging with a woven belt


    Outer Packing : Carton/wooden box


    Stock : Great Supplying Ability


    Supply a sample : Yes




    Dimensions


    d
    8 mm
    Bore diameter
    D
    16 mm
    Outside diameter
    B
    5 mm
    Width
    d1
    10.4 mm
    Shoulder diameter
    D2
    14.2 mm
    Recess diameter
    r1,2
    min. 0.2 mm
    Chamfer dimension


    Abutment Dimensions

    da
    min. 9.4 mm
    Diameter of shaft abutment
    da
    max. 10 mm
    Diameter of shaft abutment
    Da
    max. 14.6 mm
    Diameter of housing abutment
    ra
    max. 0.2 mm
    Radius of shaft or housing fillet



    Calculation Data

    C
    1.33 kN
    Basic dynamic load rating
    C0
    0.57 kN
    Basic static load rating
    Pu
    0.024 kN
    Fatigue load limit
    90 000 r/min
    Reference speed
    45 000 r/min
    Limiting speed
    kr
    0.015
    Minimum load factor
    f0
    8.9
    Calculation factor

    Product Picture


    Recommended Model



    32005-X轴承 FAG S6200-2RSR FAG RTW617 FAG PCJT35-N-FA125 FAG 32232-A-N11CA FAG 22314-E1-K+H2314


    FAG CSXF140 FAG 61815-2RSR-Y FAG CSXA045 FAG 3317-M FAG 23236-E1A-M FAG 6010-2RSR


    FAG 61820-2RSR-YFAG B71914-C-2RSD-T-P4SFAG B7230-E-T-P4SFAG 22217-E1-K+AHX317FAG GAKR14-PWFAG SL024960 and


    other model


    We also provide Brand Bearing


    If you need, please contact us,Catalog and sample can be offered,let me the model you need,i will quote to you For reference.


    TIMKEN,FAG,SKF,INA,NSK,NTN,KOYO,ASAHI,IKO Bearing



    Packing , Payment , Delievry and Stock


    Packaging
    1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet
    2)Industrial Bearings packaginga)plastic tube + carton + pallet
    b). plastic bag +kraft paper + carton + pallet
    3)According to the requirement of customers'
    Payment
    1) T/T:30% deposit, 70% should be paid before shipment.
    2) L/C at sight. (high bank charge, not suggest, but acceptable )
    3) 100% Western Union in advance. (especially for air shipment or small amount)
    Delivery
    1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient )
    2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive )
    3) More than 200 KGS, we will send by sea. ( Cheapest, but long time )
    Stock
    1)Availability and supply capacity on a certain basis

    Quality SKF 628/8-2Z , 628/8-2RSRadial/Deep Groove Ball Bearing - Round Bore, 8 mm ID, 16 mm OD, 5 mm Width, Double Shielded for sale
