    22213 E Spherical Roller Bearing - 65 mm ID, 120 mm OD, 31 mm Width, Straight Bore, Open, Steel Cage，Factory product

    Ask Lasest Price
    Brand Name : SKF
    Model Number : 22213 E
    Price : USD 0.5-10 PCS
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000 PCS/MON
    Delivery Time : 3-15 DAYS
    • Product Details
    • Company Profile

    22213 E Spherical Roller Bearing - 65 mm ID, 120 mm OD, 31 mm Width, Straight Bore, Open, Steel Cage，Factory product



    Bearing Type : Spherical Roller Bearing


    Brand :SKF


    Bore Type : Cylindrical


    Outer Ring Type : Not Split


    Static Load Capacity : 48540 lbf


    Scope application : Industria and Construction Machinery


    Inner Packing : Carton/wooden box, packaging with a woven belt


    Outer Packing : Carton/wooden box


    Stock : Great Supplying Ability


    Supply a sample : Yes



    Bearing Specification


    d
    65 mm
    		Bore diameter
    D
    120 mm
    		Outside diameter
    B
    31 mm
    		Width
    d2
    ≈ 80.1 mm
    		Shoulder diameter inner ring
    D1
    ≈ 106 mm
    		Shoulder/recess diameter outer ring
    b
    6 mm
    		Width annular lubrication groove at outer ring
    K
    3 mm
    		Diameter lubrication hole (outer ring)
    r1,2
    min. 1.5 mm
    		Chamfer dimension outer ring

    Abutment Dimensions

    da
    min. 74 mm
    		Abutment diameter shaft
    Da
    max. 111 mm
    		Abutment diameter housing
    ra
    max. 1.5 mm
    		Fillet radius
    C
    198 kN
    		Basic dynamic load rating
    C0
    216 kN
    		Basic static load rating
    Pu
    24 kN
    		Fatigue load limit
    5 000 r/min
    		Reference speed
    7 000 r/min
    		Limiting speed


    Product Picture


    Recommended Model


    GE40ES-2RS,GE45ES-2RS,GE50ES-2RS,GE60ES-2RS,GE70ES-2RS,GE80ES-2RS,GE90ES-2RS,GE100ES-2RS,GE110ES-2RS,GE120ES-2RS,GE140ES-2RS,GE160ES-2RS,XB-3,XB-4,XB-5


    Packing , Payment , Delievry and Stock


    Packaging
    1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet
    2)Industrial Bearings packaginga)plastic tube + carton + pallet
    b). plastic bag +kraft paper + carton + pallet
    3)According to the requirement of customers'
    Payment
    1) T/T:30% deposit, 70% should be paid before shipment.
    2) L/C at sight. (high bank charge, not suggest, but acceptable )
    3) 100% Western Union in advance. (especially for air shipment or small amount)
    Delivery
    1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient )
    2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive )
    3) More than 200 KGS, we will send by sea. ( Cheapest, but long time )
    Stock
    1)Availability and supply capacity on a certain basis
