SKF 361206 R Crowned Yoke Roller - Chrome Steel, 72 mm Roller Diameter, 30 mm Bore, 16 mm Roller Width, Sealed

Product Categories

JFZ BEARING CO.,LTD

Contact Now

SKF 361206 R Crowned Yoke Roller - Chrome Steel, 72 mm Roller Diameter, 30 mm Bore, 16 mm Roller Width, Sealed

Ask Lasest Price
Brand Name :	SKF
Model Number :	361206 R
Price :	USD 0.5-10 PCS
Payment Terms :	L/C, T/T, Western Union, MoneyGram
Supply Ability :	1000 PCS/MON
Delivery Time :	3-15 DAYS

Add to Cart

Product Details
Company Profile

SKF 361206 R Crowned Yoke Roller - Chrome Steel, 72 mm Roller Diameter, 30 mm Bore, 16 mm Roller Width, Sealed

Bearing Type : Crowned Yoke Roller	Brand :SKF
Bore Type : Cylindrical	Closure Type : Sealed
Internal Clearance : C3	Scope application : Industria and Construction Machinery
Inner Packing : Carton/wooden box, packaging with a woven belt	Outer Packing : Carton/wooden box
Stock : Great Supplying Ability	Supply a sample : Yes

DIMENSIONS

D	72 mm	Outside diameter
d	30 mm	Bore diameter
B	16 mm	Width
d1	≈40.3 mm	Shoulder/recess diameter inner ring
D1	≈54.1 mm	Recess diameter outer ring
R	400 mm	Profile running surface (crown) outer ring
r1,2	min.1 mm	Chamfer dimension

CALCULATION DATA

C	17.4 kN	Basic dynamic load rating
C0	9.5 kN	Basic static load rating
Pu	0.4 kN	Fatigue load limit
Fr	max.14.6 kN	Maximum dynamic radial load
F0r	max.20.8 kN	Maximum static radial load
	5 300 r/min	Limiting speed
f0	13.8	Calculation factor

Product Picture

Recommended Model

GE40ES-2RS,GE45ES-2RS,GE50ES-2RS,GE60ES-2RS,GE70ES-2RS,GE80ES-2RS,GE90ES-2RS,GE100ES-2RS,GE110ES-2RS,GE120ES-2RS,GE140ES-2RS,GE160ES-2RS,XB-3,XB-4,XB-5

Packing , Payment , Delievry and Stock

Packaging
1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet
2)Industrial Bearings packaging	a)plastic tube + carton + pallet
	b). plastic bag +kraft paper + carton + pallet
3)According to the requirement of customers'
Payment
1) T/T:30% deposit, 70% should be paid before shipment.
2) L/C at sight. (high bank charge, not suggest, but acceptable )
3) 100% Western Union in advance. (especially for air shipment or small amount)
Delivery
1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient )
2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive )
3) More than 200 KGS, we will send by sea. ( Cheapest, but long time )
Stock
1)Availability and supply capacity on a certain basis

SKF 361206 R Crowned Yoke Roller - Chrome Steel, 72 mm Roller Diameter, 30 mm Bore, 16 mm Roller Width, Sealed
