Home > THK BEARING >

THK Cam Follower Cf-a CF8UU Cf8uu-a 450316 Shipsameday

Product Categories

JFZ BEARING CO.,LTD

Contact Now

Ask Lasest Price
Brand Name :	THK
Model Number :	CF8UU
Price :	USD 0.5-10 PCS
Payment Terms :	L/C, T/T, Western Union, MoneyGram
Supply Ability :	1000 PCS/MON
Delivery Time :	3-15 DAYS

Add to Cart

Category	Cam Followers	Roller Type	Cylindrical Outer Ring
Outer Diameter D(Ø)	19	Outer Ring Width C(mm)	11
Thread(mm)	M8×1.25	Fastening Methods	Hex Socket on Head Side Only
Material	Carbon Steel	Roller Lining	No
Cam Follower Type	Standard	Stud	With Stud
Unit	Metric System	Roller Guiding Method	With Cage
Basic Dynamic Load Rating(kN)	4.17	Basic Static Load Rating(kN)	4.65
Allowable Rotational Speed(rpm)	14000	Sealing Structure	UU: With Seal
Track Load Capacity(kN)	4.02	Dedicated Grease Fitting Included	No
Max. Allowable Load(kN)	4.73	RoHS	10

Category	Cam Followers	Fastening Methods	Hex Socket on Head Side Only	Roller Lining	No
Cam Follower Type	Standard	Stud	With Stud	Unit	Metric System
Dedicated Grease Fitting Included	No

UULip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded), Temperature Range -30℃/+100℃. If Letter R Is In The Suffix, Than The Cam Follower Is With Crowned Outer Ring, Otherwise It's A Cylindrical Running Surface (X)

Product Picture

Packing , Payment , Delievry and Stock

Packaging
1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet
2)Industrial Bearings packaging	a)plastic tube + carton + pallet
	b). plastic bag +kraft paper + carton + pallet
3)According to the requirement of customers'
Payment
1) T/T:30% deposit, 70% should be paid before shipment.
2) L/C at sight. (high bank charge, not suggest, but acceptable )
3) 100% Western Union in advance. (especially for air shipment or small amount)
Delivery
1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient )
2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive )
3) More than 200 KGS, we will send by sea. ( Cheapest, but long time )
Stock
1)Availability and supply capacity on a certain basis
