SKF 32228 J2 Tapered Roller Bearing Chrome Steel - 140 mm Bore, 250 mm OD, 68 mm Cone Width, 58 mm Cup Width

SKF Taper roller bearing priced cup & cone together 140mm inside x 250mm outside x 71.75mm width, also known as 32228J2

Tapered roller bearings consist of four interdependent components: the cone (inner ring), the cup (outer ring), the tapered rollers (rolling elements) and the cage (roller retainer). Tapered roller bearings are uniquely designed to manage both thrust and radial loads between a rotating and non-rotating member. The steeper the cup angle, the greater the ability of the bearing to handle thrust loads.

Industries:
Aerospace, agriculture, automotive, heavy truck, cement, aggregate, coal, oil and gas, construction, gear drives, machine tools, mining, paper, metals, rail and wind.

Benefits:
Enhanced performance in demanding applications.

DIMENSIONS

d	140 mm	Bore diameter
D	250 mm	Outside diameter
T	71.75 mm	Total bearing width
d1	≈191.53 mm	Inner ring shoulder diameter
B	68 mm	Width inner ring
C	58 mm	Width outer ring
r1,2	min.4 mm	Corner radius inner ring
r3,4	min.3 mm	Corner radius outer ring
a	59.503 mm	Distance pressure point

ABUTMENT DIMENSIONS

da	max.159 mm	Abutment diameter shaft
db	min.156.5 mm	Abutment diameter shaft
Da	min.210 mm	Abutment diameter housing
Da	max.236.5 mm	Abutment diameter housing
Db	min.238 mm	Abutment diameter housing
Ca	min.8 mm	Abutment housing - axial space at the large side face/ both sides of the outer ring
Cb	min.13.5 mm	Abutment housing - axial space at the small side face/ both sides of the outer ring
ra	max.4 mm	Fillet radius
rb	max.3 mm	Fillet radius

CALCULATION DATA

Basic dynamic load rating	C	691 kN
Basic static load rating	C0	1 000 kN
Fatigue load limit	Pu	100 kN
Reference speed		1 900 r/min
Limiting speed		2 600 r/min
Calculation factor	e	0.43
Calculation factor	Y	1.4
Calculation factor	Y0	0.8

MASS

Mass bearing

14.2 kg

Product Picture

Packing , Payment , Delievry and Stock

Packaging
1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet
2)Industrial Bearings packaging	a)plastic tube + carton + pallet
	b). plastic bag +kraft paper + carton + pallet
3)According to the requirement of customers'
Payment
1) T/T:30% deposit, 70% should be paid before shipment.
2) L/C at sight. (high bank charge, not suggest, but acceptable )
3) 100% Western Union in advance. (especially for air shipment or small amount)
Delivery
1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient )
2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive )
3) More than 200 KGS, we will send by sea. ( Cheapest, but long time )
Stock
1)Availability and supply capacity on a certain basis
