    NSK HR 320/28 XJ Tapered roller bearings, single row, japan, Complete. NSK 32028 (28X52X16)- NSK Popular item

    Ask Lasest Price
    Brand Name : NSK
    Model Number : HR 320/28 XJ
    Price : USD 0.5-10 PCS
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 1000 PCS/MON
    Delivery Time : 3-15 DAYS
    • Product Details
    • Company Profile

    NSK HR 320/28 XJ Tapered roller bearings, single row, japan, Complete. NSK 32028 (28X52X16)- NSK Popular item

    Description and application of NSK 32028 bearing 28*52*16mm Taper roller bearing HR 320/28 XJ


    NSK 32028 bearing 28*52*16mm Taper roller bearing HR 320/28 XJ included cup and cone there two parts. Cup is outer ring, Cone comprises rollers, cage, inner ring. And the inner ring with the rollers and cage can be fitted separately from the outer ring.


    NSK 32028 bearing 28*52*16mm Taper roller bearing HR 320/28 XJ is generally used to support combined load mainly consisting of radial load. The carrying capacity of axial load depends on the contact angle of the raceway of outer rings. The bigger the contact angle is, the stronger the capacity will be.


    NSK 32028 bearing 28*52*16mm Taper roller bearing HR 320/28 XJ is suitable for automobiles, truck, rolling mill, mining machinery, construction machine, agriculture machine, metallurgy, and plastic machines.


    DIMENSIONS

    d
    28 mm
    Bore diameter
    D
    52 mm
    Outside diameter
    T
    16 mm
    Total bearing width
    d1
    41.3 mm
    Inner ring shoulder diameter
    B
    16 mm
    Width inner ring
    C
    12 mm
    Width outer ring
    r1,2
    min.1 mm
    Corner radius inner ring
    r3,4
    min.1 mm
    Corner radius outer ring
    a
    12.414 mm
    Distance pressure point

    ABUTMENT DIMENSIONS

    da
    max.34 mm
    Abutment diameter shaft
    db
    min.35 mm
    Abutment diameter shaft
    Da
    min.45 mm
    Abutment diameter housing
    Da
    max.46 mm
    Abutment diameter housing
    Db
    min.49 mm
    Abutment diameter housing
    Ca
    min.3 mm
    Abutment housing - axial space at the large side face/ both sides of the outer ring
    Cb
    min.4 mm
    Abutment housing - axial space at the small side face/ both sides of the outer ring
    ra
    max.1 mm
    Fillet radius
    rb
    max.1 mm
    Fillet radius

    CALCULATION DATA

    Basic dynamic load ratingC
    39 kN
    Basic static load ratingC0
    38 kN
    Fatigue load limitPu
    4 kN
    Reference speed
    10 000 r/min
    Limiting speed
    13 000 r/min
    Calculation factore
    0.43
    Calculation factorY
    1.4
    Calculation factorY0
    0.8

    MASS

    Mass bearing
    0.14 kg


    Product Picture

    NSK HR 320/28 XJ Tapered roller bearings, single row, japan, Complete. NSK 32028 (28X52X16)- NSK Popular itemNSK HR 320/28 XJ Tapered roller bearings, single row, japan, Complete. NSK 32028 (28X52X16)- NSK Popular itemNSK HR 320/28 XJ Tapered roller bearings, single row, japan, Complete. NSK 32028 (28X52X16)- NSK Popular itemNSK HR 320/28 XJ Tapered roller bearings, single row, japan, Complete. NSK 32028 (28X52X16)- NSK Popular item


    Packing , Payment , Delievry and Stock


    Packaging
    1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet
    2)Industrial Bearings packaginga)plastic tube + carton + pallet
    b). plastic bag +kraft paper + carton + pallet
    3)According to the requirement of customers'
    Payment
    1) T/T:30% deposit, 70% should be paid before shipment.
    2) L/C at sight. (high bank charge, not suggest, but acceptable )
    3) 100% Western Union in advance. (especially for air shipment or small amount)
    Delivery
    1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient )
    2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive )
    3) More than 200 KGS, we will send by sea. ( Cheapest, but long time )
    Stock
    1)Availability and supply capacity on a certain basis
